  • MJ-Beam230
  • MJ-Beam230

MJ-Beam230

MJ-Beam230

● Voltage: AC100-240V 50/60Hz

● Light bulb: OSRAM 230W 7R (color temperature: 8500K, life: 2000 hours)

● Channel mode: 16 international standard DMX512 channels

● Control mode: self-propelled, voice control, master-slave, DMX

● Horizontal scanning: 540° (16bit precision scanning)

● Vertical scanning: 280° (16bit precision scanning)

● Optics: 3 lens lens sets, zoom 0°-3.9°

● Electronic focusing; 20 meters, 60000 LUX

● Color plate: 14 color chips + white light,

● Rainbow effect with two-way rotation

● Pattern plate: 17 rotating pattern pieces + white circle,

● Patterned jitter and pattern arbitrary positioning function

● Prism disk: 8-16 prism, which can rotate in the positive and negative directions and has a prism

● Positioning function

● Strobe: The double boring strobe frequency can be up to 13 times per second.

● and can choose random strobe and pulse strobe

● Dimming: 0%~100% linear dimming

● Atomization: 0%~100% linear atomization

● Panel display: LCD display

● Function: DMX control switch bulb

● Weight: 17KG

● Packing size: 460*460*560mm (single light carton)


 Channel function

Channel Channel function
1 CHPAN
2 CHTILT
3 CHPAN fine 16bit
4 CHTILT fine 16bit
5 CHPAN/TILT scanner speed
6 CHFrost
7 CHStrobe
8 CHDim ming
9 CHColor Wheel
10 CHColor Wheel
11 CHGobo
12 CHGobo shaking
13 CHFocusing
14 CHFace prism
15 CHPrism Rotation
16 CHLamp ControlReset
