ART-NET-8
ART-NET-8● Network signal: ART NET TCP IP
● Number of signal channels: 8 DMX512 outputs and inputs
● Working voltage: AC 100V~240V 47/60HZ
● Weight: gross weight 2.08KG net weight 2.3KG
Functional features:
● Software independent research and development is by no means a duplicate version
● CPU adopts advanced ARM Cortex-m4
● Each path of output signal is isolated independently by photoelectricity, and the isolated power supply is 2000V DC
● Console that supports all ART NET network protocols, such as pearl expert, touch tiger, MA, flying pig, etc
● Conventional DMX512 signals can be converted into ART NET network signals
● The signal output card seat adopts the original Swiss NEUTRIK three-core seat (optional five-core seat)
● Equipment firmware can be upgraded through USB flash drive or network
● System parameters can be set by LCD screen or network
● Brushed aluminum alloy shell, standard 1U 19-inch rack mount
